XBD-A Test Stand for Various Diesel Mechanical Pumps and Injectors

FOB Reference Price:Get Latest Price
US $2,000-8,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Xinbaodi
Model Number:
XBD-A
Power:
Electronic
Usage:
Auto Testing Machine
Color:
Green, Blue, Yellow
Item Weight:
1200kg
Voltage:
220v/380v
Motor Powers:
7.5kw,11kw,15kw,22kw,30kw,etc
Size:
2100*940*1160
Certification:
ISO 9001
Material:
Stainless steel
External testing:
Done
Is Customized:
Yes
Supply Ability
Supply Ability:
1000 Set/Sets per Year
Packaging & Delivery
Packaging Details
Fumigation-free wooden case
Port
Qingdao
Lead Time :
Within one week after order confimation

                          General Introduction About the XBD-A Diesel Pump Test Bench

Functions



 1 The host machine frequency conversion speed regulation. The regulation speed is about 4000 rotation speed /min



2Oil metering counting. Main principal axis rotation speed, use 4 screen display and digital display

3The oil temperature, use 3 screen display and digital display

4 The manual speed regulation and rotate speed multi –gear advance setting

5 0-0.25Mpa air supply output , built-in type blast pump

6 It has DC12V and DC24V stable power output

7 The host machine is channel steel structure; the complete structure is compact and steady

8 The oil sump tank can realize right and left rotation, and also up and down regulation

9 The test bench has urgent brake switch

10 It adopts advanced frequency conversion governor, with high precision rotate speed

11 The test bench has under voltage, over pressure, super heating and over loading protection function

12 The test bench has very low noise

13The test bench has high mechanical efficiency and save energy



TypeTechnical characteristicOutput power(KW)
 test cylinders 12
 RPM 0-40005.5
 ten speed preset
 with 12v/24v DC power7.5
 digital display of oil count times
XBD-Adigital display of temperature11
 with air supply
 control temperature of fuel15
 stroke counting 50-9999
 standard injectors ZS12SJI18.5
 the oil filter precision 5μ
 height of principal axis center 125mm
 color green,dark green,or any color22







Taian Xinbaodi Experimental Equipement Co.,Ltd, is the leading manufacturer specialized in producing and exporting Diesel Fuel Injection System testing equipments in China. is available for the following products.





1)Traditional diesel fuel injection pump



2)CR(Common Rail pump Tester)



3)CRI(Commom Rail Injectors Tester)



4)Injectors Test stand



5)In-line electronic controller pumps



6)EUI/EUP test system



7)Nozzle Tester



8)PT-CUMMIN pump



9)EDC(Electronic Diesel Controller)



10)Many spares parts of pump
