Small scale and simply operation common rail injector test bench CRIA200

FOB Reference Price:Get Latest Price
US $1,600-2,100 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Engine Analyzer
Voltage:
220/380v, 220v/380v
Power:
5.5/7.5/11/15/18.5/22, 5.5/7.5/11/15/18.5/22KW
Certification:
ISO9001(ISO9001), ISO9001(ISO9001)
Applicable Models:
DELPHI/DENSO/SIEMENS(on request)
Place of Origin:
Shandong, China (Mainland)
Brand Name:
XBD
Model Number:
CRIA200
Warranty:
12 Months, 1year
External Testing:
Done
Is customized:
Yes
Item Length:
750mm
Item Width:
650mm
Item height:
500mm
Item weight:
80KG
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Packaging:export wood carton
Package Size:length 850mm* width 600mm*height 665mm
Quatity:one container can load 6 sets.
Port
QING DAO/GUANG ZHOU/SHANG HAI
Lead Time :
2 weeks after order confirmation

 Small scale and simply operation common rail test bench XBD-CRIA200



Taian Xinbaodi Experimental Equipement Co.,Ltd, is the leading manufacturer specializing in producing and exporting Diesel Fuel Injection System testing equipments in China. is available for the following products.



1)Traditional diesel fuel injection pump



2)CR(Common Rail pump Tester)



3)CRI(Commom Rail Injectors Tester)



4)Injectors Test stand



5)In-line electronic controller pumps



6)EUI/EUP test system



7)Nozzle Tester



8)PT-CUMMIN pump



9)EDC(Electronic Diesel Controller)



10)Many spares parts of pumps





.CRIA200 can be used to test the following pumps:  DENSO, DELPHI, SIEMENS and the last of SIEMENS is available on request.





.Technical parameters





Control range

Control accuracy

Injection open pressure

24v/80v/150v

Stage regulator

Injection open frequency

0-1000HZ

1HZ

Injection open hold time

0-65535us

1us

Delivery counts

0-1000

1 times

Fuel pressure control

0-200MPA

1MPA

Pump Model

CP1/CP2/CP3/HP0

Control way

PID

Power

220V

Work Temperature

0-40°C

Relative Humidity

20~90%RH



.Functions

1 Checking of the solenoid valve of injectors.
2 Measurement of the delivery and overflow of CRI.
3 Watching of CRI injector's spray.
4 Checking of the sealing of CRI.
5 Checking of the opening pressure of injectors.
6 Checking of the sealing of injectors.
7 Watching of the injector's spray.
1 Feeding pressure : 0-180Mpa.
2 Pressure gauge : Feeding  pressure gauge : 0-250Mpa
                   Air gauge :0-1.6Mpa.
3 Graduate :90ml/2 piece.
4 Fuel tank :2.5L.
5 Air in: 0.8Mpa ,  36L/Min.
6 Electrical power in: AC220V/50(60)Hz.

.The color you want to has many choices



Our commpany pay attention to the products of quality so we confirm that you must be satisfy with our equipments.
